ACT Xtreme Pressure Plate / Street Solid Disc Clutch Kit | 1990-1999 1G/2G DSM (MB1-XTSD)
ACT Xtreme Pressure Plate / Street Solid Disc Clutch Kit | 1990-1999 1G/2G DSM (MB1-XTSD)
Couldn't load pickup availability
Advanced Clutch XT/Perf Street Rigid Clutch Kit - MB1-XTSD
MB1-XTSD kit features an Xtreme pressure plate for the most demanding driver. ACT Xtreme pressure plates use exclusive diaphragm design to increase clamp load, reduce deflection and maximize clutch life. All diaphragms endure a four-stage, heat-treating process for unparalleled performance. ACT pressure plates have precision cover stampings to provide rigidity and consistency. The ACT Performance street rigid-hub discs feature premium organic materials with high copper content for better heat transfer and steel-backed lining for greater burst strength and durability. The chrome-moly hub is heat-treated for strength and durability. Rivet design and materials are carefully selected for maximum strength. These discs are the minimum weight street disc for faster shifts. ACT's Street rigid-hub discs provide race-proven performance with street manageability.
Features
- Friction Surface Diameter (Inches) 8.8
- Input Shaft Diameter (Inches) 7/8
- Friction Surface Diameter (mm) 224
- Item Description XT/Perf Street Rigid
- Product Weight (lbs.) 10.8
- Disc Type Rigid Street Disc
- Pressure Plate Type Xtreme
- Torque Capacity Over OE 64%
- Torque Capacity (ft/lbs.) 415
- Spline Count 20
Benefits
- Feel: Moderate to heavy pedal effort, smooth positive engagement, increased gear rattle
- Life: Longer clutch life achieved through ACT's exclusive diaphragm design, rigid design may increase spline wear
- Quality: Precisely balanced and uses premium organic friction materials for heat tolerance, faster recovery from overheating and prevents warping of mating surfaces
- Recommended Use: Recommended for street and race use
- ACT Difference: 100% clamp load tested and dynamically computer balanced for smooth high RPM reliability
Applications
- 1990-1999 1G / 2G DSM
- 1991-1999 Mitsubishi 3000GT
- 1991-1996 Dodge Stealth
- 2003-2004 Chrysler Sebring
- 2000-2005 Mitsubishi Eclipse
- 1992-1995 Mitsubishi Expo
- 1991-1999 Mitsubishi Galant
- 1992-1994 Plymouth Colt Vista
What's In The Box?
- Perf Street Rigid Disc - 3000310
- P/PL Xtreme - MB010X
- Alignment Tool - AT20
- Release Bearing - RB210
